Replace Install Wire Harness for 1998 – Up Acura, Honda, and Suzuki
Review: 5 - "A masterpiece of literature" by , written on May 4, 20020

Replace Install Wire Harness for 1998 – Up Acura, Honda, and Suzuki

Available:In Stock
  • Product SKU: 1721-11
$9.99 USD
  • Order within

Key Features:   XT1721-11

  • Our premium quality wire harnesses help to install your aftermarket stereo with ease
  • Designed to be a replacement for the original factory harness
  • Pre-stripped to make installation quick and easy. Follow EIA color-coded and special wire function as per compatible model.
  • Wire Length: 8 Inch

Item Description:
Thinking of replacing your aftermarket harness, then the Xtenzi wire harness is a must for a quick and clean installation. Our premium quality wire harnesses help to install your aftermarket stereo with ease. The Xtenzi harness eliminates cutting your OE radio plug and allows you to reinstall your factory receiver if necessary. After connecting the wire harness, your install is made simple with our E.I.A. color coded wires. Please note these harnesses are designed to be a replacement for the original factory harness. They are only designed to work on Factory radios which are NOT 'factory amplified' or 'premium sound' models. Although they may still fit these radios, we're unable to offer any form of assistance or support when purchasing this for 'premium sound radios' and often times they won't even connect to premium sound radios/systems without additional parts or OEM sound Amplifiers.

Compatible with the following Select Vehicles Models: (Only For REF, REC, and RAK Factory Radios)


  • 2000 - 2003 Acura CL
  • 2006 - 2013 Acura RL
  •   2001 - 2006 Acura MDX
  • 1999 - 2005 Acura RL
  • 2002 - 2006 Acura RSX
  • 2002 - 2006 Acura RSX (Type S)
  • 1999 - 2003 Acura TL
  •   2004 - 2008 Acura TSX


  • 1998 - 2002 Honda Accord
  • 1999 - 2000 Honda Civic
  •  2001 - 2005 Honda Civic
  •  2001 - 2005 Honda Civic Hybrid
  • 2002 - 2005 Honda Civic Si
  • 1999 - 2001 Honda CR-V
  •  2002 - 2006 Honda CR-V
  • 2002 - 2006 Honda Element
  • 2007 - 2012 Honda Element
  •  2001 - 2006 Honda Insight
  • 1999 - 2004 Honda Odyssey
  • 2005 - 2007 Honda Odyssey
  •  2003 - 2008 Honda Pilot
  • 1999 - 2001 Honda Prelude
  •  2006 - 2008 Honda Ridgeline
  •  2000 - 2006 Honda S2000



  • 2002 - 2002 Suzuki Aerio
  • 2003 - 2004 Suzuki Aerio
  • 2005 - 2006 Suzuki Aerio
  • 2003 - 2005 Suzuki Grand Vitara
  • 2006 - 2013 Suzuki Grand Vitara
  • 2007 - 2013 Suzuki SX4
  • 2003 - 2006 Suzuki XL-7

Technical Specifications:

­­­­­­­­­­­­­­­­­­­Brand Name: Xtenzi

Model Number: XT1721-11

Wire length: 8 In

Connector Color:

Connector no Of Pins: 22Pin.

What is Included within the Package:
1 x Xtenzi Wire Harness Harness

EIA-Wire Harness Connections:

  • Yellow 12V Constant
  • Red 12V Accessory
  • Black - Ground
  • Orange Dash Light Dimmer/Illumination
  • Green Left Rear Speaker (+)
  • Green with Black Stripe Left Rear Speaker (-)
  • White Left Front Speaker (+)
  • White with Black Stripe Left Front Speaker (-)
  • Purple Right Rear Speaker (+)
  • Purple with Black Stripe Right Rear Speaker (-)
  • Gray Right Front Speaker (+)
  • Gray with Black Stripe Right Front Speaker (-)

* Some wire functions may be different, please read your Radio install guide carefully or ask an installer.
